Channel size

1000mm (width) × 1000mm (height)

Conveyor speed

0.22m/s

Conveyor maximum load

250kg

Film security

ISO1600 film security

Line resolution

0.0787mm Single solid copper wire

Penetration resolution

Can achieve a single solid core copper wire with a diameter of 0.1 6mm

Spatial resolution

Level: 1.0mm; Vertical: 1.0mm

Penetration

40mm Steel plate

Tube voltage

100~160 KV(adjustable)

Tube current

0.4~1 .2mA(adjustable)

Beam emission angle

80°

Single dose

≦0.8μSv/h

Leakage dose rate

≦0.16μSv/h

Power loss

1.0KW(maximum)

Operating Voltage

220VAC(±10%) 50/60Hz

Cooling cycle

Sealed oil cooling / 100%

X-ray sensor

L-shaped photodiode array detector (multi-energy), 12-bit accuracy

Beam direction

Bottom type

Penetration resolution

Can achieve a single solid core copper wire with a diameter of 0.1 6mm

monitor

19.5-inch high resolution LCD display

Computer operating system

Windows7 64Bit

One-button shutdown

Shut down the key only, the device automatically shuts down safely, reducing equipment failure

Energy saving and environmental protection design

Energy saving and environmental protection design

Image resolution and gray image

Resolution: 1920×1080; gray image: 65536

Image Processing

24bit real-time processing, color/black-and-white image, reverse image display, edge enhancement, object outline edge and image detail are more clear, image is highlighted, image is dimmed, image is pulled back before 20 pictures, alarm function, image retrieval.

Image saving, selection, enlargement and recovery

Real-time storage of 100,000 frames, 1-9 selections can be selected, and 2-68 times real-time magnification, the image display returns to the original state, and the image can be recalled.

Multi-energy color display

Organics are shown in orange, inorganics are shown in blue, and mixtures are shown in green
High-energy, low-energy penetrating display and switching: Improve the contrast between the bright and dark areas of the image, making the easy-to-penetrate area and the difficult-to-penetrate area clearer, and the two energy switches are displayed.

Fault self-diagnosis function

Automatically judge when the fault occurs, and promptly give prompt information for easy maintenance.

Drug explosive assisted detection

Assist in detecting dangerous goods such as some typical drug explosives.
Unique features: date and time display, working status, image thumbnail display, operator identification code, baggage count, emergency stop, power-on self-diagnosis function, network interface, system operation and X-ray emission timing.

Storage temperature / humidity

-20℃ ~ + 60℃ / 20% ~ 95%(not condensing)

Working temperature / humidity

0℃ ~ 45℃ / 20% ~ 95%(not condensing)

Noise level

55dB

Leakage current test

2.1mA

One-touch switch

One-touch switch control

LED display

At the import and export end, the device is equipped with an LED display, which can display the prompt text such as “Please queue in order, all luggage pass security check”. (Text can be optionally entered).

Video image acquisition

The wide-angle camera is used to capture the video image, and the video image of the packaged person and the image of the object to be inspected and the X-ray image of the object to be inspected are displayed one by one on the same computer display screen, and the video image can clearly record and play back the package action of the holder. Or take the package action.
